Quadra is the brand name for capillary hoses developed to connect pressure test points, gauges, pressure switches, oil return and oil level equalization lines.

Need for spare components?

Discover the entire Quadra range with just a few clicks

Want to build your own assembly?

Configure your factory made assembly following your system's needs

Quadra DN2

I.D.: 2mm

Applications

The most efficient solution to connect pressure test points, gauges, pressure switches.

Quadra DN4

I.D.: 4mm

Applications

High performing hose for pressure test points, gauges, pressure switches, oil return and oil level equalization lines.

Quadra DN6

I.D.: 6mm

Applications

The largest ID quadra hose, it is ideal for oil return circuits and oil level equalization lines.

Features

Thermoplastic capillary hose reinforced with textile braids. Light, flexible and long lasting, Gomax Quadra offers a very low permeability for the majority of the refrigerant gasses exceeding EN 1736 CLASS 1.

Gomax Product Finder

Quadra Assembling

Hose components

Select by locating products on drawing

Assembled hose

Select by hose internal diameter

Gomax Product Finder

Quadra DN2 Hose features

Features

Select hose type, color and length

COLOUR

LENGTH

10 meter

The hose is provided in coils of 10 meters length without any interruption

50 meter

The hose is provided in coils of 50 meters length without any interruption

CLASS

Standard

UL / CSA Certified

Reset

Gomax Product Finder

Quadra DN2 Accessories

Accessories

Select the accessories for your hose

Hand Pliers

Packaging

Part No. RXA007 - 1 pcs.

Hydraulic Pliers

Packaging

Part No. RXA005 - 1 pcs.

Copper Gasket 3/8”

Packaging

Part No. WRP504 - 50 pcs. blister

QUADRA 3/8 fitting plugs

Packaging

Part No. WRW914 - 50 pcs. blister

Cutter

Packaging

Part No. WXA004 - 1 pcs.

Blades

Packaging

Part No. WXB004 - 2 pcs.

QUADRA electric plier bundle

Battery hydraulic crimping machine 45 kN
Battery Li-Ion 18V 1.5Ah
Battery charger
USB cable and Software (CD)
Set of dies DN2, DN4 and DN6
Case
Dimensions of the case: 450 x 360 x 140 mm
Total weight: 5,3 Kg

Packaging

Part No. RXA011 - 1 pcs.

QUADRA electric plier full

Battery hydraulic crimping machine 45 kN
Battery Li-Ion 18V 1.5Ah
Battery charger
USB cable and Software (CD)
Set of dies DN2, DN4 and DN6
Case
Spare Li-Ion 18V 1.5Ah battery
DC bench power supply
Dimensions of the case: 450 x 360 x 140 mm
Total weight: 6,5 Kg

Packaging

Part No. RXA012 - 1 pcs.

Removable valve Opener

Packaging

Part No. WTD2Z1 - 50 pcs.

Copper Gasket 1/4”

Packaging

Part No. WRP502 - 50 pcs.

QUADRA 1/4 fitting plugs

Packaging

Part No. WRW912 - 50 pcs.

QUADRA Case empty

Packaging

Part No. MR293 - 1 pcs.

QUADRA Case Complete

10 m. ref. 0780K
10 m. ref. 0780BK
1 ref. RXA007
1 ref. WXA004
1 ref. WXB004
20 ref. WBA02C
20 ref. WBB02C
10 ref. WCA02C

10 ref. WPB0C1
10 ref. WPB0C2
50 ref.WRP502
10 ref. WDN22C
50 ref. WTD2Z1
4 ref. WPA2C1
2 ref. WZE2C1
5 ref. XPB2C3

Packaging

Part No. W00005 - 1 pcs.

QUADRA floor display unit with DN2

A useful Floor Display unit holding an assortment of QUADRA products and accessories.
A simple way to promote and support your business in your retail network.

Dimensions in cm
Width: 65
Depth: 46
Height: 159
Height with crowner: 199

40 pcs - KBA02C
40 pcs - KBB02C
40 pcs - KCA02C
40 pcs - KPB0C1
40 pcs - KPB0C2
50 pcs - WZE2C1
40 pcs - KDN22C
20 pcs - KPD2C1
4 pcs - WXB004
2 pcs - WXA004
2 pcs - RXA007
100 pcs - WRP502
100 pcs - WTD2Z1
60 m - 0780BK
60 m - 0780K

QUADRA floor display unit with DN4

20 pcs - KBA02C
20 pcs - KBB02C
20 pcs - KCA02C
20 pcs - KPB0C1
20 pcs - KPB0C2
20 pcs - KDN22C
20 pcs - KPD2C1
40 pcs - KBA02M
30 pcs - KCA02M
20 pcs - KBA04M
20 pcs - KCA04M
20 pcs - KPB0M1
20 pcs - KDN22M
20 pcs - KPB2M2
4 pcs - WXB004
2 pcs - WXA004
2 pcs - RXA007
100 pcs - WRP502
100 pcs - WTD2Z1
20 m - 0780BK
20 m - 0780K
20 m - 0789BK
20 m - 0789K

QUADRA floor display unit with DN6

20 pcs - KBA02C
20 pcs - KBB02C
20 pcs - KCA02C
20 pcs - KPB0C1
20 pcs - KPB0C2
20 pcs - KBA02M
20 pcs - KCA02M
20 pcs - KBA04M
20 pcs - KCA04M
20 pcs - KPB0M1
20 pcs - KDN22M
30 pcs - KBA02N
20 pcs - KBA04N
30 pcs - KCA02N
20 pcs - KCA04N
4 pcs - WXB004
2 pcs - WXA004
2 pcs - RXA007
100 pcs - WRP502
100 pcs - WTD2Z1
20 m - 0780BK
20 m - 0780K
20 m - 0789BK
20 m - 0789K
20 m - 0786K
20 m - 0786BK

Packaging

Part No. W00006 - 1 pcs.

QUADRA Clamps

A specific clamp for the bench vice to ease the assembly of DN4 Reusable Fittings. Can be used for any operation with DN2-DN4-DN6 hoses without damaging the hose.

Packaging

Part No. RXB007 - 1 pcs.
